These specifications allow you to compare your Scarlett 2i2 with other devices and make sure they’ll work together. If you’re not familiar with these specifications, don’t worry you don’t need to know this information to use your Scarlett 2i2 with most devices
Where possible, we measure all performance figures following AES17.
|
Recording |
|
|---|---|
|
Supported Sample Rates |
44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz |
|
Bit Depth |
24-bit |
|
Microphone Inputs |
|
|---|---|
|
Frequency Response |
20Hz - 20kHz ± 0.06dB |
|
Dynamic Range (A-weighted) |
116dB |
|
THD+N |
-100dB (-1dBFS @ 8dB Gain) |
|
Noise EIN (A-Weighted) |
-127dBu |
|
Maximum Input Level (at minimum gain) |
16dBu |
|
Gain Range |
69dB |
|
Input Impedance |
3kΩ |
|
Line Inputs |
|
|---|---|
|
Frequency Response |
20Hz - 20kHz ± 0.05dB |
|
Dynamic Range (A-weighted) |
115.5dB |
|
THD+N |
-100dB (-1dBFS @ 8dB Gain) |
|
Maximum Input Level (at minimum gain) |
22dBu |
|
Gain Range |
69dB |
|
Input Impedance |
60kΩ |
|
Instrument Inputs |
|
|---|---|
|
Frequency Response |
20Hz - 20kHz ± 0.15dB |
|
Dynamic Range (A-weighted) |
113dB |
|
THD+N |
-80dB (-1dBFS @ 8dB Gain) |
|
Maximum Input Level (at minimum gain) |
12dBu |
|
Gain Range |
62dB |
|
Input Impedance |
1MΩ |
|
Line Outputs 1 and 2 (balanced) |
|
|---|---|
|
Frequency Response |
20Hz - 20kHz ± 0.02dB |
|
Dynamic Range (A-weighted) |
120dB |
|
THD+N |
-109dB |
|
Maximum Output Level |
16dBu |
|
Output impedance |
100Ω |
|
Headphone Outputs |
|
|---|---|
|
Frequency Response |
20Hz - 20kHz ± 0.1dB @ 33Ω / 300Ω |
|
Dynamic Range (A-weighted) |
112dB @ 33Ω 115dB @ 300Ω |
|
Maximum Output Level |
2.5dBu into 33Ω 10dBu into 300Ω |
|
Maximum Output Power |
32mW into 33Ω 22mW into 300Ω |
|
THD+N |
-99dB @ 33Ω (Minimum) -108dB @ 300Ω (Minimum) |
|
Output impedance |
50Ω |
|
Analogue Inputs |
|
|---|---|
|
Connectors |
Two rear panel Neutrik® XLR connectors Two front panel Neutrik® 6.35mm (1/4”) jack sockets |
|
Mic/Line switching |
Automatic Connecting a 6.35mm jack to the front panel disables microphone input. |
|
Phantom Power (48v) |
Front panel 48V (phantom power) button or switch in software |
|
Line/Instrument switching |
Front panel Inst button or switch in software |
|
Auto Gain |
Front panel Auto button or switch in software |
|
Clip Safe |
Front panel Safe button. |
|
AIR function |
Front panel Air button or switch in software |
|
Analogue Outputs |
|
|---|---|
|
Balanced Outputs |
Two rear-panel Neutrik®6.35mm (1.4") TRS jack sockets |
|
Headphone Output |
Front panel stereo 6.35mm (1.4") TRS jack socket |
|
Main Output Level Control |
Front panel analogue control with pre-fade output level meter |
|
Headphones Level Control |
Front panel analogue control |
|
Other I/O |
|
|---|---|
|
USB |
One USB 2.0 Type-C connector for data and power - 900mA One USB Type-C power connector - 5V DC 4.5W |
|
Front Panel Indicators |
|
|---|---|
|
Channel Selection |
White/Green LEDs for channels 1 and 2 |
|
Select button |
White/Green Select LED |
|
48V |
White/Green 48V LED (depending on the selected channel) |
|
Inst |
White/Green Inst LED (depending on the selected channel) |
|
Auto |
White Auto LED to initiate Auto Gain |
|
Clip Safe |
White/Green Safe LED (depending on the selected channel) |
|
Air Mode |
White, green, amber Air LED (depending on the selected channel and selected Air mode) |
|
Output Level Meter |
Three-colour LED ring around Output control. |
|
USB |
USB |
|
Direct Monitor |
Three-state |
|
Weight and Dimensions |
|
|---|---|
|
Weight |
595g (1.31lbs) |
|
Height |
47.5mm (1.87") |
|
Width |
180mm (7.09") |
|
Depth |
117mm (4.60") |
|
Environmental |
|
|---|---|
|
Operating Temperature |
40°C / 104°F Maximum ambient operating temperature |
