ISA One dimensions are illustrated in the diagram above.
Allow for an additional 75mm [3”] behind the unit to allow for cable connections.
ISA One comes in a freestanding case fitted with a top-mounted carrying handle. It weighs and is equipped with rubber feet for table mounting.
ISA One generates little significant heat and is cooled by natural convection. Vents are provided at each side; ensure that when mounted close to other equipment these vents are not obstructed. Do not position the unit immediately above any other equipment which generates significant heat, for example, a power amplifier.
Note
The maximum operating environmental temperature is 40°C / 104°F.
ISA One is mains-powered. It incorporates ‘Universal’ power supplies which can operate on any AC mains voltage from 100 V to 240 V. The AC connections are made via standard 3-pin IEC connectors on the rear panel.
A mating IEC cable is supplied with each unit – this should be terminated with a mains plug of the correct type for your country.
The AC power consumption of the ISA One is 35 W.
Note
There are no fuses in ISA One or other user-replaceable components of any type. Please refer all servicing issues to the Customer Support Team (see Customer Support and Unit Servicing).
